Please note that bike specifications are subject to change without prior notice
Specifications
Frame : Addict eRIDE Disc HMX, Endurance geometry / Replaceable Derailleur Hanger, Fully Internal cable routing, Range Extender IncludedFork: Addict eRIDE HMX Flatmount Disc, 1 1/4"-1 1/2" Excentric Carbon steerer
Derailleur: Shimano Dura-Ace Di2 RD-R9250, 24 Speed Electronic Shift System
Shift Levers: Shimano Dura-Ace ST-R9270, 24 Speed Electronic Shift System
Front Derailleur: Shimano Dura-Ace Di2 FD-R9250 Electronic Shift System
Number Of Gears: 24
Brake Front: Shimano BR-R9270 Hyd.Disc
Brake Rear: Shimano BR-R9270 Hyd.Disc
Brake Disc Front: SM-MT800 CL rotor 160mm
Brake Disc Rear: SM-RT86 6B rotor 160mm
Wheelset: Syncros Capital 1.0 40e Disc, 24 Front 12x100mmTA /32 Rear 12x142mmTA
Tire Front: Schwalbe PRO ONE Microskin, TL-Easy, Fold, 700x30C
Tire Rear: Schwalbe PRO ONE Microskin, TL-Easy, Fold, 700x30C
Handlebar: Syncros Creston iC SL, Carbon combo
Headset: Syncros Addict RC Integrated
Saddle: Syncros Belcarra Regular 1.0
Seat Post: Syncros Duncan SL D-shape
Crankset: Shimano Dura-Ace FC-R9200, Hollowtech II 50x34T
Bottom Bracket: Shimano SM-BB92-41B
Drive: Shimano Dura-Ace CN-M9100-12
Sprockets: Shimano Dura-Ace CS-R9200-12, 11-34
Rear Light: Syncros iL rear
Bidex Mo: MO51
Bidex Mp: MP30
Bidex Mt: MT25
Motor: Mahle X20 Motor Hub drive 55Nm max Torque / EU: 25kmh / US: 20mph
Battery: Mahle 36V-236Wh + xTra Power Bottle Cage Battery 36v-171Wh
Battery Capacity: 407
Display: Mahle HMI, Bluetooth /Pulsar One Display/ Dedicated Smartphone app
Charger: Mahle 100-240V-4A Active Charger
Bodysize Min: 160
Bodysize Max: 170
Weight: 10,65
Permissible Total Weight: 120
Stack: 511
Reach: 388
Seat Tube Length: 490
Seat Tube Angle: 74,5
Top Tube Length: 530
Head Tube Length: 102
Head Tube Angle: 71
Stem Length: 90
Wheelbase: 994
Standover: 740
Chainstay Length: 410
Fork Rake: 45
Fork Installation Length: 379
Bottom Bracket Height: 275
Bottom Bracket Drop: 70
