Please note that bike specifications are subject to change without prior notice
Specifications
Frame : Spark Alloy SL 6011, Integrated Suspension Technology, Flex Pivot / Adjustable head angle, Syncros Cable Integration System, BB92 / UDH Interface / 12x148mm with 55mm ChainlineFork: RockShox Judy Silver TK Solo Air, 15x110mm QR axle / 42mm offset / Tapered Steerer, 2-Modes / Reb. Adj. / Lockout / 130mm travel
Fork Suspension Travel: 130
Rear Shock: X-Fusion NUDE 5 RLX Trunnion, SCOTT custom w. travel / geo adj., 3 modes: Lockout-Traction Control -Descend, Reb. Adj., Travel 120-80-Lockout / T165X45mm
Rear Shock Suspension Travel: 120
Derailleur: Shimano XT RD-M8100 SGS, Shadow Plus / 12 Speed
Shift Levers: Shimano Deore SL-M6100-R / Rapidfire Plus
Number Of Gears: 12
Brake Front: Shimano MT501 Disc
Brake Rear: Shimano MT501 Disc
Brake Disc Front: Shimano SM-RT54 CL / 180mm
Brake Disc Rear: Shimano SM-RT54 CL / 180mm
Rims: Syncros X-30SE / 32H / 30mm
Tire Front: Schwalbe Wicked Will / 29x2.4", Performance / TLR / Foldable / Addix
Tire Rear: Schwalbe Wicked Will 29x2.4", Performance / TLR / Foldable / Addix
Hub Front: Shimano HB-MT410-B CL / 15x110mm
Hub Rear: Shimano FH-MT410-B CL / 12x148mm / Micro Spline
Spokes: Stainless Black 15G / 1.8mm
Handlebar: Syncros Fraser 2.0 DC Alloy 6061 D.B., mini Rise / back sweep 8deg. / 760mm
Stem: Syncros DC 3.0, Syncros Cable Integration System, 0deg. rise / 6061 Alloy / 31.8mm / 1 1/8"
Headset: Syncros - Acros Angle adjust Cable Routing HS System, +-0.6deg. head angle adjustment, ZS56/28.6 ? ZS56/40 MTB
Grips: Syncros Women Pro lock-on grips
Saddle: Syncros Savona 2.5 (V-Concept) Channel
Seat Post: Syncros Duncan Dropper Post 2.5, 31.6mm / S size 100mm, M size 125mm / L size 150mm
Remote System: SCOTT TwinLoc 2 Technology, Suspension Dropper Remote, 3 Suspension modes
Crankset: Shimano FC-MT512-1, 55mm CL / 32T
Bottom Bracket: Shimano BB-MT500 / shell 41x92mm
Drive: KMC X12
Sprockets: Shimano Deore CS-M6100-12 / 10-51 T
Bodysize Min: 160
Bodysize Max: 170
Weight: 14,96
Permissible Total Weight: 128
Stack: 608
Reach: 410
Seat Tube Length: 415
Seat Tube Angle: 75,7
Top Tube Length: 561
Head Tube Length: 90
Head Tube Angle: 65,8
Stem Length: 50
Stem Angle: 0
Handlebar Width: 760
Handlebar Backsweep: 8
Wheelbase: 1145
Standover: 759
Chainstay Length: 438
Fork Installation Length: 130
Bottom Bracket Height: 332
Bottom Bracket Drop: 44
Dropper Travel: 100
