Please note that bike specifications are subject to change without prior notice
Specifications
Frame : Alloy Frame / Virtual 4 link kinematic VLK, 27.5" and 29" compatible / geo adj. / Boost 148x12mm, 140mm travel / Bosch Gen4 / Integr. removable Battery, Tapered Headtube E2, Central Kickstand Mount, Range Booster ReadyFork: Marzocchi Z2 Air / eMTB+, Rail 3 / 3-Modes / 15x110mm QR axle / tapered steerer, 44mm offset / Reb. Adj. / Lockout / 140mm travel
Fork Suspension Travel: 140
Rear Shock: X-Fusion NUDE Trunnion, SCOTT custom w. travel / geo adj., 3 modes: Lockout-Traction Control-Descend, Reb. Adj., Travel 140-90-Lockout / 185x50mm
Rear Shock Suspension Travel: 140
Derailleur: SRAM NX Eagle / 12 Speed
Shift Levers: SRAM SX Eagle Single Click
Number Of Gears: 12
Brake Front: SRAM DB8 4 Piston Disc
Brake Rear: SRAM DB8 4 Piston Disc
Brake Disc Front: Centerline CL rotor 200mm
Brake Disc Rear: Centerline CL rotor 200mm
Rims: Syncros MD30 / 32H / 30mm / Pin Joint, Tubeless ready
Tire Front: Maxxis Rekon / 29x2.6" / 60TPI Wire Bead, EXO, Dual
Tire Rear: Maxxis Rekon / 29x2.6" / 60TPI Wire Bead, EXO, Dual
Hub Front: Formula CL-811 / 15x110mm
Hub Rear: Formula CL-148S / Boost 148x12mm
Spokes: Stainless Black
Handlebar: Syncros Hixon 2.0 Rise / Alloy 6061D.B., 20mm rise / 8deg. / 740mm
Stem: Syncros FL2.0 / 6061 Alloy, L-Shape Spacer Top Cap / 31.8mm / 6deg. / 1 1/8"
Headset: Syncros ER2.0 Press Fit E2 / Tapered 1.5"-1 1/8", OD 52/62mm / ID 44/56mm
Grips: Syncros Comfort lock-on grips
Saddle: Syncros Capilano
Seat Post: Syncros Duncan Dropper Post 2.5, 31.6mm / S size 100mm / M size 125mm / L size 150mm
Remote System: SCOTT TwinLoc 2 Technology, Suspension Dropper Remote, 3 modes
Crankset: FSA CK-320 / 165mm / 34T
Drive: SRAM SX Eagle
Sprockets: SRAM PG1210 / 11-50 T
Front Light: Bosch Light Cable pre-installed
Rear Light: Bosch Light Cable pre-installed
Bidex Mo: MO12
Bidex Mp: MP20
Bidex Mt: MT25
Motor: Bosch Performance CX, EU: 25kmh / INT: 20mph
Battery: PowerTube 500Wh
Battery Capacity: 500
Display: Bosch Purion
Charger: 4A Charger
Bodysize Min: 160
Bodysize Max: 170
Weight: 23,4
Permissible Total Weight: 128
Stack: 627
Reach: 422
Seat Tube Length: 411
Seat Tube Angle: 76,3
Top Tube Length: 575
Head Tube Length: 120
Head Tube Angle: 64,8
Stem Length: 50
Wheelbase: 1215
Standover: 749
Chainstay Length: 465
Fork Rake: 44
Fork Installation Length: 150
Bottom Bracket Height: 350
Bottom Bracket Drop: 30
