Please note that bike specifications are subject to change without prior notice.
Specifications
Frame : Genius Alloy 6061, Integrated Suspension Technology, Virtual 4 Link kinematic / Adjustable head angle, Syncros Cable Integration System, BB92 / UDH Interface / 12x148mm with 55mm ChainlineFork: Marzocchi Z2 Air Rail, 3-Modes / 15x110mm QR axle / tapered steerer, 44mm offset / Reb. Adj. / Lockout / 150mm travel
Fork Suspension Travel: 150
Rear Shock: X-Fusion NUDE 5 RLX Trunnion, SCOTT custom w. travel / geo adj., 3 modes: Lockout-Traction Control-Descend, Reb. Adj., Travel 150-100-Lockout / T185X55mm
Rear Shock Suspension Travel: 150
Derailleur: SRAM NX Eagle 12 Speed
Shift Levers: SRAM SX Eagle Trigger
Number Of Gears: 12
Brake Front: Shimano MT501 Disc
Brake Rear: Shimano MT501 Disc
Brake Disc Front: Shimano SM-RT30 CL / 203mm
Brake Disc Rear: Shimano SM-RT30 CL / 180mm
Rims: Syncros X-30S / 32H / 30mm / Sleeve Joint
Tire Front: Maxxis Dissector / 60TPI Foldable, Tubeless Ready / EXO
Tire Rear: Maxxis Dissector / 60TPI Foldable, Tubeless Ready / EXO
Hub Front: Formula CL-811 / 15x110mm
Hub Rear: Formula CL-148S / 12x148mm
Spokes: Stainless Black 15G / 1.8mm
Handlebar: Syncros Hixon 2.0 Alloy 6061 D.B., 12mm Rise / back sweep 8deg. / 780mm
Stem: Syncros AM 2.0, Syncros Cable Integration System, 4deg. rise / 6061 Alloy / 31.8mm / 1 1/8"
Headset: Syncros - Acros Angle adjust Cable Routing HS System, +-0.6deg. head angle adjustment, ZS56/28.6 ? ZS56/40 MTB
Grips: Syncros Endurance lock-on grips
Saddle: Syncros Tofino 2.5 Regular
Seat Post: Syncros Duncan Dropper Post, 31.6mm / S size 130mm / M size 150mm / L XLsize 170mm
Remote System: SCOTT TwinLoc 2 Technology, Suspension Dropper Remote, 3 Suspension modes
Crankset: SRAM SX Eagle DUB, 55mm CL / 32T
Bottom Bracket: SRAM DUB PF 92 MTB Wide / shell 41x92mm
Drive: SRAM CN SX Eagle
Sprockets: SRAM SX-PG1210 / 11-50 T
Bodysize Min: 160
Bodysize Max: 170
Weight: 15,8
Permissible Total Weight: 128
Stack: 617
Reach: 430
Seat Tube Length: 380
Seat Tube Angle: 76,8
Top Tube Length: 570
Head Tube Length: 90
Stem Length: 40
Stem Angle: 4
Handlebar Width: 780
Handlebar Rise: 12
Handlebar Backsweep: 8
Wheelbase: 1182
Standover: 729
Chainstay Length: 440
Fork Rake: 44
Fork Installation Length: 571
Bottom Bracket Height: 343
Bottom Bracket Drop: 33
Dropper Travel: 130
