Please note that bike specifications are subject to change without prior notice.
Specifications
Frame : Spark Carbon HMF Mainframe with Alloy 6011 Swingarm, Integrated Suspension Technology, Flex Pivot / Adjustable head angle, Syncros Cable Integration System, BB92 / UDH Interface / 12x148mm with 55mm ChainlineFork: FOX 34 Float Rhythm Air Grip, 3-Modes / Kabolt 15x110mm axle / tapered steerer, 44mm offset / Reb. Adj. / Lockout / 130mm travel
Fork Suspension Travel: 130
Rear Shock: FOX NUDE 5T EVOL Trunnion, SCOTT custom w. travel / geo adj., 3 modes: Lockout-Traction Control-Descend, Custom large Air volume / DPS / Reb. Adj., Travel 120-80-Lockout / T165X45mm
Rear Shock Suspension Travel: 120
Derailleur: Shimano XT RD-M8100 SGS, Shadow Plus / 12 Speed
Shift Levers: Shimano Deore SL-M6100-IR / Rapidfire Plus, Ispec EV clamp
Number Of Gears: 12
Brake Front: Shimano Deore M6120 4 Piston Disc
Brake Rear: Shimano Deore M6120 4 Piston Disc
Brake Disc Front: Shimano SM-RT64 CL / 180mm
Brake Disc Rear: Shimano SM-RT64 CL / 180mm
Rims: Syncros X-30SE / 32H / 30mm, Tubeless ready
Tire Front: Schwalbe Wicked Will 29x2.4" EVO, Super Race / TLE / 67EPI / Addix Speed Soft
Tire Rear: Schwalbe Wicked Will 29x2.4" EVO, Super Race / TLE / 67EPI / Addix Speed Grip
Hub Front: Formula CL-811 / 15x110mm
Hub Rear: Formula CL-148M / 12x148mm / Micro Spline, Syncros Axle w/Removable Lever, with 6mm Allen, T30 and T25 Tools
Spokes: Stainless Black 15G / 1.8mm
Handlebar: Syncros Fraser 2.0 DC Alloy 6061 D.B., mini Rise / back sweep 8deg. / 760mm
Stem: Syncros DC 2.0, Syncros Cable Integration System, 0deg. rise / 6061 Alloy / 31.8mm / 1 1/8"
Headset: Syncros - Acros Angle adjust Cable Routing HS System, +-0.6deg. head angle adjustment, ZS56/28.6 ? ZS56/40 MTB
Grips: Syncros Performance XC lock-on grips
Saddle: Syncros Tofino 2.0 Regular, CRMO rails
Seat Post: Syncros Duncan Dropper Post 2.0, 31.6mm / S M size 125mm / L size 150mm / XL size 170mm
Remote System: SCOTT TwinLoc 2 Technology, Suspension Dropper Remote, 3 Suspension modes
Crankset: Shimano SLX FC-M7120-1 / Hollowtech 2, 55mm CL / 32T
Bottom Bracket: Shimano BB-MT500 / shell 41x92mm
Drive: Shimano Deore CN-M6100
Sprockets: Shimano Deore CS-M6100-12 / 10-51 T
Bodysize Min: 160
Bodysize Max: 170
Weight: 13,5
Permissible Total Weight: 128
Stack: 608
Reach: 410
Seat Tube Length: 415
Seat Tube Angle: 75,7
Top Tube Length: 561
Head Tube Length: 90
Head Tube Angle: 65,8
Stem Length: 50
Stem Angle: 0
Handlebar Width: 760
Handlebar Backsweep: 8
Wheelbase: 1145
Standover: 759
Chainstay Length: 438
Fork Installation Length: 130
Bottom Bracket Height: 332
Bottom Bracket Drop: 44
Dropper Travel: 125
